Solution Overview
IP•Tube T1 encapsulates full and fractional T1 and
TDM circuits, along with their framing & signaling bits into IP packets. IP•Tube T1’s T1 Over IP, T1 Over Ethernet connection provides for the transparent interconnection of PBXs, Telecom Switches and T1 based communication systems via LANs, WANs, MANs, Satellite and Wireless Ethernet.
Applications
Technical Specification
Data Sheet Download
User Manual Download
How to Order

 IP•Tube T1

Transparent T1 interface for T1 over IP Voice and Data
The IP•Tube T1 encapsulates full and fractional T1 and TDM circuits, along with their framing and signaling bits, into IP packets. The IP•Tube’s T1 Over IP, T1 Over Ethernet connection provides for the transparent interconnection of PBXs, Telecom Switches and T1 based communication systems via LANs, WANs, MANs, and Wireless Ethernet.
  IPTube T1 Features
Transparent Interconnect
IP•Tube T1 transparent operation maintains the proprietary signaling required to support PBX features such as call conferencing, call forwarding, caller ID and SS7. Legacy phone equipment investment is preserved. Transparent support for Modem, Fax, or Data circuits. The IP•Tube T1 has a T1 interface that connects directly to the T1/DS1 interface of Phone Systems or T1 Data Communication Equipment.
Lossless Data Compression Option
The IP•Tube T1C detects idle/redundant data within each DS0 resulting in as much as 56 to 1 bandwidth savings. T1 over IP bandwidth is not consumed by silent or redundant circuits. Management of the IP•Tube T1 is accomplished with a Command Line Interface that is accessed through a Console or Telnet connection. Common templates provide for cut and Paste configuration.
Service Quality Packet Prioritizing
The IP•Tube T1 uses the Type of Service byte in the IP packets to prioritize the encapsulated T1 frames. The setting of the TOS byte can be used to ensure that the real time TDM data from the IP•Tube T1 is ensured high priority.
Pay-As-You-Grow Compression Upgrade
At any time, the T1 port on the IP•Tube T1 can be upgraded to Lossless Data Compression with a simple software-based license key installation. If upon installation, you determine that your IP•Tube T1 is best deployed with Lossless Data Compression, you're still in business with the port field compression upgrade!
Rack Mount Kit
The IP-Tube family is ready for your most demanding central office or data center environments. With the Rack Mount Kit, IP
Tube products are easily installed in 19" and 23" racks. Easy access to both front and rear sides facilitates technician maintenance procedures.
